GLASSMATE®-XL Graphite
Interested in GLASSMATE®-XL graphite?
Contact Us
Interested in GLASSMATE®-XL graphite?
Contact Us
Interested in GLASSMATE®-XL graphite?
Contact Us
Applications
- Conditions that lead to extreme wear
- Pick up of heavy containers
- Precision thread pick up
- Productions that have longer run times
- Long handling component lifetimes
Specifications
| Particle size |
1 µm (40 µin) |
| Apparent density |
1.74 g/cm3 (0.063 lb/in3) |
| Compressive strength | 162 MPa (23,500 psi) |
| Flexural strength1 | 95 MPa (15,250 psi) |
| Shore hardness | 88 |
| Coefficient of thermal expansion | 8.1 µm/m°C (4.5 µin/in°F) |
| Thermal conductivity2 | 77 W/m-K (45 Btu-ft/hr/ft2°F) |
| Purity | <3000 ppm ash |
| Oxidation threshold3 | 450°C (842°F) |
1Measured using three-point bend method. 2Approximate values taken at room temperature; as temperature increases, thermal conductivity decreases. 3Oxidation threshold defined as temperature at which oxidation weight loss after 24 hours is approximately 1%. (Size 0.5" x 0.5" x 1").
Documentation
Videos
GLASSMATE® Glass Handling
